BLDC4259无刷马达/圆型铁壳

用途: 泵浦



MODEL VOLTAGE NO LOAD AT MAXIMUM EFFICIENCY STALL
OPERATING
RANGE
NOMINAL SPEED CURRENT SPEED CURRENT TORQUE OUTPUT EFF CURRENT TORQUE
rpm A rpm A g-cm mN-m W % A g-cm mN-m
BLDC4259B0W0 ---------- 24.0V CONSTANT 7000 0.34 6464 2.61 809 79.31 53.70 87 23.52 8127 796.76
BLDC4259B1W2 ---------- 24.0V CONSTANT 4000 0.19 3413 1.16 627 61.47 21.97 82 7.67 4786 469.22
马达的出轴长度及性能参数,EMC 对策可依客人要求做调整,详情可询问相关业务人员。
